NanoPC-T6 Plus Mini Computer WiFi Router, Rockchip RK3588 SoC 6TOPS NPU, Dual 2.5G Ethernet, M.2 NVMe, 16GB LPDDR5 RAM 64GB eMMC, Multi-OS Open Source IoT Gateway (Full Kit,with Case)

- Hardware Spec - SoC: Rockchip RK3588 CPU: Quad-core ARM Cortex-A76 (up to 2.4GHz) + Quad-core Cortex-A55 (up to 1.8GHz) GPU: Mali-G610 MP4, compatible with OpenGL ES 1.1, 2.0, 3.2; OpenCL up to 2.2; Vulkan 1.2 VPU: 8K@60fps H.265 & VP9 decoder; 8K@30fps H.264 decoder; 4K@60fps AV1 decoder; 8K@30fps H.264 & H.265 encoder NPU: 6TOPs, supports INT4/INT8/INT16/FP16 RAM: 64-bit 8GB/16GB/32GB LPDDR5 eMMC Flash: 32GB/64GB/256GB eMMC (HS400 mode) Nor Flash: 32MB SPI Nor Flash microSD: Supports up to SDR104 mode Ethernet: 2 × PCIe 2.5G Ethernet USB: 1 × USB 3.0 Type-A1 × Full-Featured USB Type‑C (USB 3.0 + DP output up to 4Kp60)2 × USB 2.0 Type-A Video Input: 1 × Standard HDMI IN (up to 4Kp60)2 × 4-lane MIPI-CSI (compatible with MIPI V1.2) Video Output: 2 × Standard HDMI OUT (HDMI 2.1/2.0/1.4) 1 × up to 8K@60fps (7680×4320@60Hz)1 × up to 4K@60fpsSupports RGB/YUV format (up to 10bit)1 × USB Type-C DP output (up to 4Kp60)2 × 4-lane MIPI-DSI (compatible with MIPI DPHY 2.0 / CPHY 1.1) Audio: 1 × 3.5mm stereo headphone jack1 × 4-pin connector for dual analog microphone input GPIO: 40-pin 2.54mm headerSupports up to 2 × SPIs, 6 × UARTs, 1 × I2C, 8 × PWMs, 2 × I2Ss, 28 × GPIOs M.2 Connectors: 1 × M.2 M-Key (PCIe 3.0 x4) for NVMe SSDs (up to 2,500 MB/s)1 × M.2 E-Key (PCIe 2.1 x1 + USB 2.0 Host)1 × M.2 B-Key (USB 2.0 Host) for 4G LTE module Others: 3-pin 2.54mm Debug UART (3.3V TTL)38KHz IR receiverMask key (eMMC update), Reset button, Power button5V fan connectorUSB-C to debug serial port (1500000bps)2 × GPIO-controlled LEDs (SYS, LED1) Power: 12V DC input (5.5×2.1mm DC jack & 2-pin 3.5mm terminal) PCB: 8-layer, 110×82.5×1.6mm Operating Temperature: 0℃ to 70℃

• [Powerful Core Performance] NanoPC-T6 Plus features Rockchip RK3588 SoC with 8-core CPU (Quad-core Cortex-A76 up to 2.4GHz + Quad-core Cortex-A55 up to 1.8GHz), 16GB LPDDR5 RAM and 64GB eMMC flash. Integrated Mali-G610 MP4 GPU and 6TOPS NPU, delivering robust computing power for AI edge computing, machine vision and complex multimedia tasks.
• [Abundant Expansion Options] NanoPC-T6 Plus is equipped with three M.2 slots (M-Key for NVMe SSD up to 2500MB/s, E-Key for WiFi module, B-Key for 4G LTE module), dual 2.5G Ethernet ports, 2x HDMI output + 1x HDMI IN, 1x USB 3.0, 2x USB 2.0 and 1 full-featured USB-C (supports DP 4K60p). It also supports microSD (SDR104 mode) and TF card booting, meeting diverse hardware expansion needs.
• [8K Ultra HD Video Capability] NanoPC-T6 Plus decodes up to 8K@60p H.265/VP9, 8K@30p H.264 and 4K@60p AV1 videos, and encodes 8K@30p H.264/H.265 videos. Dual HDMI outputs support 8K@60p and 4K@60p displays respectively, with RGB/YUV 10-bit format support. HDMI IN port captures up to 4K@60p video, ideal for high-definition content creation and playback.
• [Versatile Application Scenarios] NanoPC-T6 Plus features open-source design with compact 110x82.5mm form factor. Perfect for enterprise IoT gateways, mini machine vision systems and embedded development. Suitable for commercial applications, education, multimedia editing and professional customization, supporting both industrial deployment and enthusiast exploration.
• [Extensive OS Compatibility] NanoPC-T6 Plus runs multiple operating systems including Ubuntu 20.04/22.04/24.04, Debian 11/12, Android 12/14 (Tablet/TV), FriendlyWrt 23.05/24.10, OpenMediaVault and Proxmox VE. Supports headless operation and flexible booting from eMMC/microSD card/M.2 SSD, offering a one-stop open-source platform for edge computing.
